CODELOCK 5010 Heavy Electric Mortice Latch

Description

The CL5010 is a heavy duty electronic tubular mortice latch.

External doors - low / medium / high traffic
Internal doors - low / medium / high traffic
Mortice Latch
Lever handle lock for doors hung on the left or right
Use in offices / schools / warehouses / hospitals / care homes / nurseries / hotels / leisure facilities / the home
Also available as Back to Back (CL5010BB) – Provides coded access in both directions

Available in 2 PVD finishes - Brushed Stee or Polished Brass


The outside lever turns freely without operating the latchbolt. When a valid code is entered and the blue LED lights, the lever will retract the latchbolt. When the door closes the spring latch will automatically lock the door. The key will open the door for management functions. The key may be used to set the lock into Code Free mode so that anyone can open the door without using a code. Code Free Mode can also be programmed at the keypad using the Master Code.

The lock can store up to 80 different User Codes. Codes may be 4, 5 or 6 digits long. Programming is via the keypad, using the Master Code.

The lock has fitted as standard two alarm release terminals.

REM1 is used to open the lock from a reception desk button or answer phone.
REM2 can be linked to an alarm system which, when activated by a momentary contact, will release the door for 30 minutes. This allows emergency personnel to enter the room to rapidly check that no one has been overlooked.

Product Code: C041200

Qty Price Per
1£231.88EACH
2£220.29EACH
3£208.69EACH
4£197.10EACH
5£191.30EACH
6£179.71EACH

All prices are subject to VAT

Live Stock Unavailable In Stock Usually Ships in 3-5 Working Days Checking Stock
