Coburn Straightaway 100 System - 100 Kg

Coburn STRAIGHTAWAY 100 System

FOR INTERIOR AND EXTERIOR STRAIGHT SLIDING DOORS WEIGHING UP TO 100 Kg

Application: Top hung straight sliding doors for domestic, schools. hospitals and light agricultural, industrial and commercial applications.

Range: Maximum door weight: 100 Kg Maximum door height: 2.5m Door thickness: 20 to 50mm

Door Construction: Suitable for normal timber framed construction, flush panelled, glazed or framed, ledged and braced. Adequate top rail required to provide secure fixing of hanger. Miniumum door thickness is 30mm when using floor guide channel. For metal doors of light angle or channel frame construction, minimum thickness 40mm.

Bottom Guiding: Consideration must be given to location, traffic and potential weather / wind conditions when selecting a bottom guiding system for Straightaway 100. If in any doubt please contact our sales team for advice and guidance.
